Operation 3-7
Zoomed Data Screen
The Zoomed Data screen is entered by touching in the size and count
part of the main tab display. The bottom portion of the screen
summarizes the concentrations for the currently selected location. Tap
the size and count portion of the display to switch back to the Main
tab display.
The display shows:
• Temperature
*
• Relative humidity*
• Bin sizes
• Particle count/concentration
Field
Description
Location
Label that displays information about the
currently selected location.
Manual/Automatic/Beep
Mode Indicator; refers to the “Data Count Mode”
(see section below).
Press the Start/Stop button to begin sampling in
the configured mode.
*
Temperature and Humidity are displayed only if the optional T/H probe is installed.
