Ubee Interactive Using the Status Option
Ubee EVW32C Advanced Wireless Voice Gateway Subscriber User Manual • March 2017 26
4.1.3 Using the Configuration Option
The Configuration screen allows the user to reboot the device or restore the device to
factory default values. Field descriptions follow the screen example.
Label Description
Initial Scan
Favorite Frequency
(MHz)
Allows the user to enter a favorite frequency (in MHz) for the initial scan
Apply Saves changes to the Favorite Frequency.
Downstream Bonded Channels
Channel Numbers the downstream channels.
Lock Status Displays if the device is locked successfully to a downstream channel.
Modulation
Displays the modulation method required for the downstream channel to lock on to
by the device. This method is determined by the service provider.
Frequency Displays the downstream channel frequency on which the device is locked.
Power Displays the receiver power level in decibel millivolts (dBmV) after ranging process.
SNR
Displays the signal-to-noise ratio (SNR) in decibels (dB), the desired signal level to
the background noise level.
Symbol Rate Displays the symbol rate in 1000 symbols per second.
Correctables Displays the quantity of codewords which are correctable.
Uncorrectables Displays the quantity of codewords which are uncorrectable.
Upstream Bonded Channels
Channel Numbers the upstream channels.
Lock Status Displays if the EVW32C succeeded in locking to an upstream channel.
US Channel Type Displays the channel type.
Symbol Rate Displays the symbol rate in 1000 symbols per second.
Frequency Displays the current upstream frequency in hertz.
Power Displays the current upstream transmit power in decibel millivolts (dBmV).
