Ubee Interactive Using the WLAN Option
Ubee EVW32C Advanced Wireless Voice Gateway Subscriber User Manual • March 2017 44
6.3.4 Using the Access Control Option
Use the Access Control option to configure which clients can access either the 2.4GHz
or 5GHz wireless networks. It also displays the status of currently connected clients.
Field descriptions are listed below the screen example.
Label Description
The following fields are available for configuring WPS settings for either the 2.4GHz or the 5GHz radio:
WPS Enable Check ON or OFF to enable or disable the WPS option.
WPS Mode
Allows you to choose between the 2 WPS modes:
1.PIN: User must enter the client WPS Pin.
Note: When PIN is selected, the WPS Client Pin field will appear.
2. PBC (Push Button Configuration): A software or a hardware button is pushed on both the
EVW32C and the wireless client that wishes to connect. Both devices are then in registration
mode. This is the default setting.
WPS Client Pin
This field is only visible when PIN is selected as the WPS Mode. The connecting client’s WPS
Pin number must be entered in the space provided before clicking the Connect box.
WPS Trigger
Triggers connection to the client via WPS. The WPS Client Pin must be entered into the space
provided before clicking the Connect box.
Apply Saves changes.
