Configuration menu
8. Confirm with Save.
Pull Cord Alarm
The Pull Cord Alarm can be activated optionally. It is triggered if the pull cord contact (cord) is
not detected over a defined configurable period of time, i.e. has been removed.
For more information on alarm destinations please refer to Chapter 4, "Control ports and alarm
destinations".
Procedure:
1. Select the Additional Features icon in the main menu.
2. Select Configuration.
3. Enter the five-position service PIN and confirm with OK.
4. Select one of the three operating modes.
5. Select Alarms.
6. Select Pull Cord Alarm.
7. Change the values of the following parameters:
Table 3-8 Parameter – Pull Cord Alarm
Parameters Operating Mode Value Range Standard Value
Activation BM/AM/PNG On/off On
Response Time
BM/AM 1 ... 900 s 30 s
PNG 1 ... 90 s 30 s
Prealarm Time
BM/AM 0 ... 300 s 15 s
PNG 0 ... 30 s 15 s
Alarm Destination
BM -
1
1 The alarm destination is the same in Basic Mode of the M3 Plus for all alarms and is entered under "General Settings".
112
AM/PNG (up to 32 digits) (blank)
8. Confirm with Save.
Alarm Signal
You can define the acoustic signalling of prealarms and alarms here. The following signals start
quietly and reach their configured maximum value after a short time.
Procedure:
