13
DS1083-098A
5.4. PARAMETER ASSOCIATED TO PROGRAMMING LED (1)
COLOUR
Parameter to be confi gured LED (1) Parameter value LED state (4)
Parameter 1:
door unit type LED C: Green
Main LEDs off
Secondary LEDs on steady
Parameter 2:
door unit ID LED C: Red
Address 0 LEDs off
Address 1 LEDs on steady
Parameter 3: door opener LED B: Orange
Privacy LEDs off
Free LEDs on steady
Parameter 4: call button enabling LED A: Green
No button enabled LEDs off
Only the calling button (7)
is enabled
LEDs on steady
Both buttons are enabled LEDs on blinking
Parameter 5:
(*)
call button association
with switchboard call
LED A: Red
Not active LEDs off
Arm LEDs on steady
(*) Function only possible if door unit is confi gured as main unit.
5.5. DEFAULT CONFIGURATION
Parameter Function Default
Parameter 1 Door unit type Main
Parameter 2 Door unit ID Address 0
Parameter 3 Door opener Privacy
Parameter 4 Call button enabling Both buttons enabled
Parameter 5 Call button association with switchboard call Not active
6. HOW TO RESET DEFAULT SETTINGS
Press the PROGRAM button (10) briefl y to go to confi guration state. The LEDs (1) will blink during this
step.
Then hold the BUTTON (7) pressed for longer than 10 seconds.
The door unit will generate two 2-second long beeps and all parameters will be reset before exiting
confi guration state.
7. ADVANCED CONFIGURATION (WITH WiFi CONFIGURATION)
Prepare the device as WiFi access point for advanced confi guration of the audio-video door units Ref.
1083/48 and audio door units Red. 1083/38. To start this type of confi guration, follow that shown in the
instruction booklet on the Urmet website, which can be downloaded by framing the QR Code shown below
with the camera of your smartphone or tablet:
Audio-video door unit Ref. 1083/48 Audio door unit Ref. 1083/38
http://qrcode.urmet.com/default.aspx? http://qrcode.urmet.com/default.aspx?
prodUrmet=142027&lingua=en prodUrmet=142025&lingua=en
