Valtra Q Series User Manual

PROGRAMMABLE
FUNCTIONS
HYDRAULICS
There are totally 9 different programmable hydraulic controls
in the SmartTouch armrest. The auxiliary hydraulic controls are
positioned on the armrest. The joystick, ngertip levers and
linear levers are programmable, thus you can select which
lever controls which valve.
1.
Joystick
2.
Joystick ngertip lever
3.
Upper button (Front loader selecto 3)
4.
Lower button (Front loader selecto 4)
5.
Hydraulics ngertip lever 1
6.
Hydraulics ngertip lever 2 (optional)
7.
On/off valve A (optional)
8.
On/off valve B
9.
Blue linear lever
10.
Brown linear lever
11.
Green linear lever
12.
White linear lever
13.
Master activation switch
MASTER ACTIVATION
Hydraulics, Valtra Guide steering valve, memory buttons
(U-pilot) and Isobus aux controls can all be actived via the
master activate button on the smarttouch armrest. When
starting up the tractor simply press the button on the
armrest and then select from the screen which functions
you want to activate. You can easily deactive all functions
by pressing the button again, this increases the safety while
allowing higher speeds than 25 km/h (limited by
Valtra Guide).
1.
Press button on armest
2.
Select from pop-up which functions you want to be actived.
(If nothing pressed, previously selected functions activate)
3.
Press button again to deactivate
1
2
3
23
Q Series Quick Guide
