TRA-F22x-A
CONFIGURATION
Doc: 70-00-0958A V1.0, 20221102 © Vector Controls GmbH, Switzerland Page 28-34
Subject to change without notice www.vectorcontrols.com
VECTOR
5.9 Temperature and digital inputs
5.9.1 Parameter P5xx overview
With parameter P500 P503 input type and functionality of RT1 and RT2 can be set.
With parameter P504 P505 the automatic heat/cool changeover level can be set.
With parameter P506 the built-in temperature sensor calibration (temperature offset) can be set.
If RT1/2 is set to 0 = NTC and an open or short circuit is detected, the error Err3 is generated.
Par/
Addr
Description
Data type / value
Default
R/
W
P500
Input RT1 Configuration
0 = Not assigned
1 = Control input instead of built-in
temperature sensor (NTC)
2 = Heat/cool changeover or floor
temperature sensor (NTC or DI)
3 = Occupation sensor Comfort /
Economy (DI)
4 = Occupation sensor Comfort /
Protection (DI)
5 = Door switch (DI, in combination with
occupation sensor on RT2)
6 = Electric heater overheat sensor (DI)
7 = Dew point sensor (DI)
0
R/
W
P501
Definition of RT1
0 = NTC temperature sensor
1 = Normally Open (DI)
2 = Normally Closed (DI)
0 = NTC
R/
W
P502
Input RT2 Configuration
0 = Not assigned
1 = Control input instead of built-in
temperature sensor (NTC)
2 = Heat/Cool changeover or floor
temperature sensor (NTC or DI)
3 = Occupation sensor Comfort /
Economy (DI)
4 = Occupation sensor Comfort /
Protection (DI)
5 = Not used
6 = Electric heater overheat sensor (DI)
7 = Dew point sensor (DI)
0
R/
W
P503
Definition of RT2
0 = NTC temperature sensor
1 = Normally Open (DI)
2 = Normally Closed (DI)
1 = NO
R/
W
P504
Automatic heat/cool changeover level for
cooling
Multiplier: 10
5.0…20.0 °C
15.0 °C
R/
W
P505
2-/4-pipe system: Automatic heat/cool
changeover level for heating
Floor heating system: Floor temperature limit
Multiplier: 10
20.0…40.0 °C
30.0 °C
R/
W
P506
Built-in temperature sensor calibration
Multiplier: 10; Integer (signed)
-3.0…+3.0 °C
0.0 °C
R/
W
5.9.2 P500/502: 2 = Heat/cool changeover or floor temperature sensor (NTC or DI)
Heat/cool changeover (NTC or DI)
P200 (Application mode) must be set to 3 or 5. Otherwise an error occurs (Err4).
If P501/P503 = 0 = NTC temperature sensor, the controlling mode changes to cooling mode if the temperature on RT1/2
is lower than specified in P504. The controlling mode changes to heating if the temperature on RT1/2 is higher than
specified in P505.
If RT1 and RT2 are not specified as Heat/cool changeover, the controlling mode changes to fan only. If the heat/cool
changeover sensor defined as NTC has a short circuit or open contact, the controlling mode changes to fan only.
Floor temperature sensor (NTC)
P200 (Application mode) must be set to 7 (Floor heating system) and the corresponding P501/P503 = 0 = NTC.
Otherwise, an error occurs (Err4).
If the floor temperature sensor exceeds the floor temperature limit (P505), the heating valve is turned off until the floor
temperature is 2°C lower than the floor temperature limit.
