02_04
02_05
Shock absorbers adjustment (02_04, 02_05)
The preloading of the spring can be adjusted to 4 positions using the ring nut located
in the lower part of the shock absorbers and the specific spanner supplied.
Position 1: minimum preload: rider only
Position 2 medium preloading: rider only
Position 3 medium preloading: rider and passenger
Position 4: maximum preloading: rider, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
Spring preloading increases by turning the ring nut towards «A», but decreases if the
ring nut is turned towards «B».
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
WARNING
WE RECOMMEND WEARING GLOVES WHILE CARRYING OUT THIS OPERA-
TION IN ORDER TO AVOID INJURIES.
N.B.
ACCORDING TO THE EQUIPMENT, THE VEHICLE MAY BE FITTED WITH REAR
SHOCK ABSORBERS WITH 3 POSITIONS FOR PRELOAD ADJUSTMENT.
35
