TYRE INFLATION PRESSURE
Front tyre pressure 1.8 bar
Rear tyre pressure 2.0 bar
03_07
03_08
Spark plug dismantlement (03_07, 03_08)
Removal
In order to inspect the spark plug, follow the operation described when the engine is
cold:
- Slide off the spark plug inspection cover «A» by unscrewing the screw «B».
- Slide off the spark plug tube «C».
- Remove the spark plug using the box-spanner supplied.
Fitting
- Use the box-spanner to refit the spark plug in its saddle, then tighten it. Care should
be taken while installing and fixing it with the correct inclination.
- Insert the spark plug tube «C».
- Place the inspection cover «A» and tighten the screw «B».
CAUTION
FOLLOW THESE PROCEDURES VERY CAREFULLY TO AVOID ANY SEVERE
DAMAGE THAT MAY BE CAUSED BY THE VERY POWERFUL IGNITION SYS-
TEM.
52
