Quantity: 1 RHS + 1 LHS
03_22
Front light group (03_22, 03_23, 03_24, 03_25, 03_26)
To access the bulb of the front headlight assembly, remove the upper handlebar cover
and proceed as follows:
- Remove on both sides of the vehicle the screw «A» fixing the surround of the head-
light assembly.
- Remove the surround of the headlight assembly by releasing it from the upper fixing.
03_23
- Remove the two screws «B».
65
