Engine oil level
In four stroke engines, the engine oil is used to lubricate the timing elements, the bench
bearings and the thermal group. An insufficient quantity of oil can cause serious
damage to the engine. In all four-stroke engines, a loss of efficiency in oil perform-
ance and consumption should be considered normal.
Consumption can particularly reflect the conditions of use (i.e while riding the use of
the vehicle with the accelerator predominantly open results in greater oil consump-
tion).
In order to avoid problems, it is advisable to control oil level every time the
vehicle is used.
03_01
Engine oil level check (03_01, 03_02)
Every time the vehicle is used, visually inspect the level of the engine oil when the
engine is cold (after completely unscrewing the oil cap/dipstick). The oil level should
be somewhere between the MAX and MIN index marks on the level rod; «A»; while
the oil is being checked, the vehicle must be resting on its centre stand on an even,
horizontal surface.
If the check is carried out after the vehicle has been used, and therefore with a hot
engine, the level will be lower; in order to carry out a correct check, wait at least 10
minutes after the engine has been stopped so as to get the correct level.
46
