03_42
Rear drum brake (03_42)
Operate adjusting nut «B» and loosen lock nut «A» shown in the figure. Note that
when the throttle is in idle the wheel should rotate free. After the adjustment, screw
lock nut «A».
CAUTION
BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.
03_43
Puncture (03_43)
The vehicle is equipped with Tubeless tyres (without inner tube). In the event of a
puncture, Tubeless tyres - unlike tyres with inner tubes - go flat very slowly, resulting
in a greater steering safety. In the event of a puncture, an emergency repair can be
carried out using an "inflate and repair" spray can. For a final repair, take your vehicle
to an Authorised Service Centre or Dealer. The replacement of a tyre involves re-
moving the wheel in question. Take your vehicle to an Authorised Service Centre
or Dealer for these operations.
CAUTION
TO USE THE "INFLATE AND REPAIR" SPRAY CAN PROPERLY, FOLLOW THE
INSTRUCTIONS ON THE PACKAGING.
76
