03_27
03_28
Head light adjustment (03_27, 03_28)
Proceed as follows:
- Position the vehicle in running order and with the tyres inflated to the prescribed
pressure, onto a flat surface, 10 m away from a half-lit white screen; ensure that the
longitudinal axis of the vehicle is perpendicular to the screen;
- Turn on the headlight and check that the borderline of the projected light beam on
the screen is not higher than 9/10 or lower than 7/10 of the distance from the ground
to the centre of the vehicle headlamp;
- If this is not the case, adjust the headlight by operating the screw «A».
N.B.
THE ABOVE PROCEDURE COMPLIES WITH THE EUROPEAN STANDARDS RE-
GARDING MAXIMUM AND MINIMUM HEIGHT OF LIGHT BEAMS. REFER TO THE
STATUTORY REGULATIONS IN FORCE IN EVERY COUNTRY WHERE THE VE-
HICLE IS USED.
03_29
Front direction indicators (03_29, 03_30, 03_31)
To replace the bulbs:
- Open the front case and remove the rubber cap «A».
68
