Volvo D13 User Manual

Section 01: ENGINE
PA1561 28
SPN FMI PID/SID
PID/SID
ID
FLASH
CODES
FAULT DESCRIPTION
3695 14 SID 155 2334 DPF Regen Inhibit MUX Switch Message Not
Received this Ign Cycle
3696 19 SID 155 2335 DPF Regen Force MUX Switch Message Contains
Data Error Indicator
3696 13 SID 155 2335 DPF Regen Force MUX Switch Message Contains
SNV Indicator
3696 9 SID 155 2335 DPF Regen Force MUX Switch Message Stopped
Arriving
3696 14 SID 155 2335 DPF Regen Force MUX Switch Message Not
Received this Ign Cycle
2.11 DDEC VI MCM DIAGNOSTIC CODES LIST
SPN FMI PID/SID
PID/SID
ID
FLASH
CODE FAULT DESCRIPTION
27 4 PID 27 1111 EGR Valve Position Circuit Failed Low
27 3 PID 27 1111 EGR Valve Position Circuit Failed High
27 2 PID 27 1111 EGR Valve Position Feedback Failed
27 0 PID 27 1111 EGR Valve Position Feedback Failed (High Box)
27 1 PID 27 1111 EGR Valve Position Feedback Failed (Low Box)
27 14 PID 27 1111 EGR Valve Position Positive Torque Error
27 7 PID 27 1111 EGR Valve Stuck Open
27 19 PID 27
1521
Smart Actuator Indicates EGR Position Error
51 4 SID 51 1112 Intake Air Throttle Circuit Failed Low
51 3 SID 51 1112 Intake Air Throttle Circuit Failed High
51 2 PID 51 1112 Intake Throttle Position Deviation Error
51 0 PID 51 1112 Intake Air Throttle Position High
51 1 PID 51 1112 Intake Air Throttle Position Low
51 7 PID 51 1112 Intake Throttle Auto Calibration Error
94 4 PID 94 1112 Fuel Compensation Pressure Sensor Circuit Failed Low
94 3 PID 94 1112 Fuel Compensation Pressure Sensor Circuit Failed High
94 1 PID 94 1112 Fuel Pressure Too High/Too Low
97 4 PID 97 1615 Water in Fuel Circuit Failed Low
97 3 PID 97 1615 Water in Fuel Circuit Failed High
98 1 PID 98 1114 Oil Level Circuit Failed Low
98 0 PID 98 1114 Oil Level Circuit Failed High
98 13 PID 98 1634 Oil Level Mesaurement, Configuration Error
98 14 PID 98 1634 Oil Level Mesaurement, Oil Level Too Low or Too High
100 4 PID 100 1114 Engine Oil Pressure Circuit Failed Low
100 3 PID 100 1114 Engine Oil Pressure Circuit Failed High
100 1 PID 100 1114 Engine Oil Pressure Low
100 2 PID 100 1114 Oil Pressure Plausibility - Engine Running
100 2 PID 100 1114 Oil Pressure Plausibility - Stop
103 2 PID 103 1115 Turbocharger Speed Not Plausible
103 1 PID 103 1115 Turbo Charger Speed Below Threshold (High Box)
103 0 PID 103 1115 Turbo Charger Speed Above Threshold (Low Box)
103 4 PID 103 1115 Turbo Charger Speed Sensor Circuit Failed Low
103 3 PID 103 1115 Turbo Charger Speed Sensor Circuit Failed High
108 4 PID 108 1211 Barometric Pressure Circuit Failed Low
108 3 PID 108 1211 Barometric Pressure Circuit Failed High
108 2 PID 108 1211 Ambient Pressure Plausibility Fault (Low Box)
108 20 PID 108 1211 Ambient Pressure Plausibility Fault (High Box)

Volvo D13 Specifications

Engine Specifications

engine type	Diesel four cycle/in-line direct injection engine
number of cylinders	12.8 L in-line 6
operating range	1400-1800 RPM
peak power rating	435 HP (324 kW)
peak torque rating	1650 Ft-lb (2237 Nm)
low idle	600 rpm
fast idle	2150 rpm
maximum full load revolutions	1900 rpm

Oil Capacity

oil pan capacity low limit	25 quarts/24 liters
oil pan capacity high limit	34 quarts/32 liters
total engine oil capacity with filters	41 quarts/39 liters
