Volvo D13 User Manual

Section 01: ENGINE
PA1561 8
symbol should be used. Lubricants meeting API standards have provided maximum engine life when
used together with the recommended oil and oil filter change intervals.
EO-O Premium Plus (or VDS-4) diesel engine oil is mandatory for use in all 2007 emission compliant
Volvo engines. Chassis equipped with a 2007 emission compliant engine, which can be identified by the
presence of a Diesel Particulate Filter (DPF), also require the use of Ultra Low Sulfur Diesel (ULSD) fuel.
EO-O Premium Plus oils exceed the new API service category CJ-4.
CAUTION
DO NOT add extra oil additives. Additives such as break-in oils, top oils, graphitizers, and friction-
reducing liquids are not necessary and can harm the engine.
1.3.3 Oil Change Intervals
The length of time an engine can operate before an oil change depends on the quality oil used, the type
of fuel used, fuel consumption, engine oil consumption, vehicle application, level of dust in the air, and
fuel consumption. The change intervals given in this manual are maximum intervals. If the vehicle is
operating in heavy-duty operation, dusty or off-road conditions, etc., reduce the intervals for more
frequent oil changes.
NOTE
Use the information in the table below to determine the operating condition and usage applicable to your
vehicle.
Engine Operating Condition Medium Heavy Severe
Total Fuel Consumption (mpg) More than 6 More than 4.7 More than 3.7
Total Fuel Consumption (L/100 KM) Less than 39 Less than 50 Less than 64
Engine Oil and Filter Change
Interval, miles (km) – 41 U.S. quarts (39L)
Oil capacity
35,000 (55 000) 25,000 (40 000) 15,000 (24 000)
NOTE: If idle time is greater than 25%, use the next lower drain interval.

Volvo D13 Specifications

Engine Specifications

engine type	Diesel four cycle/in-line direct injection engine
number of cylinders	12.8 L in-line 6
operating range	1400-1800 RPM
peak power rating	435 HP (324 kW)
peak torque rating	1650 Ft-lb (2237 Nm)
low idle	600 rpm
fast idle	2150 rpm
maximum full load revolutions	1900 rpm

Oil Capacity

oil pan capacity low limit	25 quarts/24 liters
oil pan capacity high limit	34 quarts/32 liters
total engine oil capacity with filters	41 quarts/39 liters

Summary

VOLVO D13 ENGINE

SYSTEM OVERVIEW

Provides an overview of the Engine Management System (EMS) functions and sensors.

ENGINE OVERVIEW

Illustrates and lists key components of the Volvo D13F engine.

ENGINE OIL AND FILTER MAINTENANCE

Covers oil quality, change intervals, filters, consumption, and checking the oil level.

POWER PLANT ASSEMBLY SERVICE

Details procedures for removing and installing the engine power plant assembly.

ENGINE MOUNTS

Describes the mounting points and supports for the engine power plant assembly.

DETROIT DIESEL SERIES 60 ENGINE

DDEC VI SYSTEM AND COMPONENTS

Introduces the DDEC VI system, harnesses, and key engine components.

DDEC VI SENSORS

Lists and describes the various sensors used by the DDEC VI system.

DDEC VI DIAGNOSTICS

Explains diagnostic system features, telltale lights, data link connectors, and reading diagnostic codes.

DIAGNOSTIC CODES LIST

Lists specific DDEC VI diagnostic codes, their SPN/FMI/PID/SID, and fault descriptions.

ENGINE OIL AND FILTER SERVICE

Covers checking oil level, recommended oil type, and oil/filter change procedures.

POWER PLANT ASSEMBLY SERVICE

Details procedures for removing and installing the engine power plant assembly.

ELECTRONIC FOOT PEDAL ASSEMBLY (EFPA) & THROTTLE POSITION SENSOR

EFPA AND TPS FUNCTIONALITY

Explains the Electronic Foot Pedal Assembly (EFPA) and Throttle Position Sensor (TPS) operation and calibration.

ENGINE TROUBLESHOOTING GUIDE

STARTING AND ROTATION ISSUES

Guides troubleshooting for engine starting and rotation problems based on symptoms and voltage readings.

EXHAUST AND FUEL RELATED ISSUES

Guides troubleshooting for exhaust fumes and fuel-related issues based on voltage readings.

SPECIFICATIONS

SERIES 60 ENGINE SPECIFICATIONS

Lists engine ratings, capacities, and filter part numbers for the Detroit Diesel Series 60.

VOLVO D13 ENGINE SPECIFICATIONS

Lists engine oil capacity, filters, and torque specifications for the Volvo D13 engine.
