Group 72 Service Procedures
6521-03-02-02
Torque/Radius Rod, Lower, Replacement
Please read “Guidelines for Working on the Volvo T-Ride
Suspension” page 19 before beginning this procedure.
1
Park the vehicle on a level surface and chock the front
wheels.
2
W7000752
Bottle jack
DANGER
Failure to properly support the nose of the axle may
result in the axle falling, which can cause serious injury
or death to anyone near or under the vehicle.
Support the nose of the axle or axles being worked on
with a bottle jack.
3
Remove the lower torque rod from between the rear axle
mounting bracket and the saddle bracket.
23
