Group 72 Service Procedures
6559-03-04-01
Grease Seals, Replacement
(Cradle Removed)
Please read “Guidelines for Working on the Volvo T-Ride
Suspension” page 19 before beginning this procedure.
Cradle Removed
1
Remove the old grease seals from the cradle.
2
Clean out the seal grooves and lightly smear clean
grease over grooves.
3
Install new grease seals. The larger of the two grease
seals fits on the inside groove and the smaller one fits
on the outer groove. The grease seal lips face each
other when in position.
4
Lightly apply grease on both seals.
5
Remove the wear ring from the cavity in the saddle
bracket and install a new wear ring. This wear ring can be
removed using a flat blade screwdriver.
6
Reinstall the cradle back onto the trunnion tube.
45
