Group 72 Service Procedures
6559-10-02-01
Cradle Bearing, Lubrication
Please read “Guidelines for Working on the Volvo T-Ride
Suspension” page 19 before beginning this procedure.
It is important that lubrication is done as follows so the
bearing is filled completely with grease.
1
W7000264
Cradle bearing lubrication points
Remove pressure relief valve located at “A” and install
a grease fitting.
2
Remove the grease fitting at “B”.
3
Fill with grease through “A” fitting until grease oozes
out of “B”.
4
Install grease fitting at “B” and fill with grease until it oozes
out around the entire seal (see arrow).
5
Remove grease fitting at “A” and reinstall the pressure
relief valve.
46
