Group 72 Service Procedures
6553-03-02-03
Cradle, Replacement
Please read “Guidelines for Working on the Volvo T-Ride
Suspension” page 19 before beginning this procedure.
1
Park vehicle on a level surface and the chock front wheels.
2
W7000269
Raising the frame
Using an air lift raise the frame and support it with jack
stands at the front and back of the suspension.
3
W6001312
Removing the U-bolts
Once the frame is supported and the suspension is
relieved of pressure, remove the four U-bolt nuts and
remove the spring saddle cap.
4
Using a lifting device, remove the upper leaf springs
Note: If there are several upper leaf springs it is best to
remove them one at a time.
41
