Group 72 Service Procedures
7116-03-02-01
V Torque Rod Anchorage, Replacement
Please read “Guidelines for Working on the Volvo T-Ride
Suspension” page 19 before beginning this procedure.
1
Park the vehicle on a level surface, and chock the
front wheels.
2
Using an air lift, raise the frame to relieve pressure from
the suspension and support it with jack stands at the
front and rear of the suspension.
3
W7000752
DANGER
Failure to properly support the nose of the axle may
result in the axle falling, which can cause serious injury
or death to anyone near or under the vehicle.
Place a bottle jack under the axle flange to prevent the
axle from rolling over.
4
W6001312
Removing the U-bolts
Remove the (4) U-bolt nuts and remove the spring
saddle cap.
5
With a lift or overhead crane remove the upper leaf
springs.
28
