Graphic Display 137
Main Menu: System Diagnostic
The menu System diagnostic has 3 sub-
menus which are not protected by a
password, and 1 sub-menu which is pro-
tected by a password.
•
Fault diagnostic
•
Cluster self test
•
Part number
Password required:
(see page 158)
•
Status test
Fault Diagnostic
MENU: Diagnostic, Fault diagnostic
A list of the vehicle’s ECUs is shown in
the menu Fault diagnostic. Each ECU is
identified by a MID number (M
essage
I
Dentifier). In addition a menu for resetting
all the fault codes is shown.
For a list of common fault codes, see page
143.
•
ABS Brakes, MID 136
•
Instrument cluster center module,
MID 140
•
Info Display (instrument cluster
graphic display), MID 234
•
SRS Airbag, MID 232
•
Cab controller (Vehicle ECU),
MID 144
•
Engine, MID 128
•
Non specified system
•
Reset all (password)
