150 Graphic Display
Part number
MENU: System diagnostics, Part number
A list of the vehicle’s electronic control
units (ECUs) is shown in the menu Part
number. Each ECU is identified by a MID
number (M
essage IDentifier).
•
ABS Brakes, MID 136
•
Instrument cluster center module, MID
140
•
Display, MID 234
•
SRS Airbag, MID 232
•
Vehicle ECU, MID 144
•
Engine, MID 128
1 The up/down buttons are used to
move the cursor in the list.
2 SELECT confirms the selection of an
ECU.
3 In the meantime, the display shows the
text:
Data transfer
in progress
please wait
4 The following text is presented:
SW: The software part number
MID 128 SW ID
03163028P01
