Fastrack M1306B User Guide
Using the M1306B Wireless CPU
®
confidential © Page: 28 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
Note:
For automotive application, it is recommended to connect the V+BATTERY line of the
M1306B directly to the battery positive terminal.
• Plug the power supply cable into the M1306B and switch on the external
power supply source.
• The M1306B is ready to work. Refer to section 5.8 for the description of AT
commands used to configure the M1306B.
5.1.3 Check the communication with the M1306B
To check the communication with the M1306B, do the following operations:
• Connect the RS232 link between the DTE (port COM) and the M1306B (DCE).
• Configure the RS232 port of the DTE as follows:
Bits per second: 115.200 bps,
Data bits: 8,
Parity: None,
Stop bits: 1,
Flow control: hardware.
• Using a communication software such as a Hyperterminal, enter the
AT↵
command. The response of the M1306B must be
OK displayed in the
Hyperterminal window.
• If the communication cannot be established with the M1306B, do the
following:
Check the RS232 connection between the DTE and the M1306B
(DCE),
Check the configuration of the port COM used on the DTE.
• Example of AT commands which can be used after getting started the
M1306B:
AT+CGMI: M1306B answer is "WAVECOM MODEM" when serial
link is OK.
AT+CPIN=xxxx: to enter a PIN code xxxx (if activated).
AT+CSQ: to verify the received signal strength.
AT+CREG?: to verify the registration of the Wireless CPU
®
on the
network.
ATD<phone number>;: to initiate a voice call.
ATH: to hang up (end of call).
For further information on these AT commands and their associated parameters,
refer to "AT Commands Interface Guide" [7].
