Wavecom FASTRACK M1306B User Manual

Fastrack M1306B User Guide
Technical Characteristics
confidential © Page: 51 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
Table 15: Power consumption (1*)
Power Consumption in
E-GSM 900/DCS 1800 MHz - GPRS class 10
E-GSM 900 DCS 1800
@ 5.5 V 2.1 A 1,88 A
@ 13,2 V 1.4 A 1.1 A
Input Peak Supply Current
Power = 33,10 dBm GSM 900
During 2TX bursts @Pcl5
Power = 30,00 dBm GSM 1800
During 2TX bursts @Pcl0
@ 32 V 610 mA 390 mA
@ 5.5 V 500 mA 390 mA
@ 13,2 V 500 mA 160 mA
Input average supply current in
communication mode
Power = 33,10 dBm GSM 900
Average 3Rx/2Tx @Pcl5
Power = 30,00 dBm GSM 1800
Average 3Rx/2Tx @Pcl0
@ 32 V 95 mA 80 mA
@ 5.5 V 2.1 A mA 1,88 A
@ 13,2 V 1.4 A 1.1 A
Input Peak Supply Current
Power = 33,10 dBm GSM 900
During 1TX bursts @Pcl5
Power = 30,00 dBm GSM 1800
During 1TX bursts @Pcl0
@ 32 V 570 mA 380 mA
@ 5.5 V 300 mA 240 mA
@ 13,2 V 125 mA 100 mA
Input average supply current in
communication mode
Power = 33,10 dBm GSM 900
Average 1Rx/1Tx @Pcl5
Power = 30,00 dBm GSM 1800
Average 1Rx/1Tx @Pcl0
@ 32 V 60 mA 50 mA
@ 5.5 V 34 mA 34 mA
@ 13,2 V 18 mA 18 mA
Input average supply current in
Idle mode with active RS232 link
(2*)
@ 32 V 9 mA 9 mA
@ 5.5 V 31 mA 31 mA
@ 13,2 V 16.5 mA 16.5 mA
disconnection by
software
@ 32 V 8.9 mA 8.9 mA
@ 5.5 V 31 mA 31 mA
@ 13,2 V 6.5 mA 6.5 mA
Input average supply current in
Idle mode with no RS232 link
(3*)
physical
disconnection
@ 32 V 4.5 mA 4.5 mA
(1*):The power consumption might vary by 5 % over the whole operating temperature range (-
20 °C to +55 °C).
(2*): In this Mode, the RF function is active and the M1306B synchronized with the network,
but there is no communication.
(3*): In this Mode, the RF function is disabled, but regularly activated to keep the
synchronization with the network. This Mode works only if the serial link is disconnected either
physically or by the software (DTE turns DTR in inactive state).
