Fastrack M1306B User Guide
Technical Characteristics
confidential © Page: 48 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
8 Technical Characteristics
8.1 Mechanical Characteristics
Table 12: Mechanical characteristics
Dimensions 73 x 54.5 x 25.5 mm (excluding connectors)
Overall Dimension 88 x 54.5 x 25.5 mm
Weight
≈ 80 grams (M1306B only)
< 120 grams (M1306B + bridles + power supply cable)
Volume
101.5 cm
3
Housing
Aluminium profiled
The next page gives the dimensioning diagram of the M1306B including the
clearance areas to take into account for the M1306B installation.
