Wavecom WMOi3 User Manual

January 2001/ version 1.4
WMOi3 Integrated Modem
confidential ©
32/61
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut
être communiqué ou divulgué à des tiers sans son autorisation préalable.
Table 16 : A/D converter pin description
Signal Pin number I/O I/O type* Description
AUXV0 17 I Analog A/D converter
*See Table 3 “operating conditions” in subdivision 4.1.1The 50-pin
connector description description
Table 17 : A/D converter electrical characteristics
Parameter Min Max Unit
Resolution 10 bits
Sampling rate 90.3 Ksps
Input signal range 0 2.5V V
ADC Reference Accuracy 0.5 %
Integral Accuracy +/- 1 LSB
Differential Accuracy +/- 1 LSB
Input Impedance ( R ) 10
MΩ
Input Impedance ( C ) 50 pF
