TECHNICAL DATA
XES SYNERGIX 8850 PRINTER OPERATOR MANUAL 49
Media specifications
Table 8. Media specifications
Media type Recommended media types:
Bond – 20 to 24 lb (80 to 90 gsm) xerographic roll paper or cut sheets
Vellum/tracing – 20 lb (80 gsm)
Film - 4-millimeter thickness, double matte, heat stable
Media supply 3 rolls/500 feet (152 meters) each
Standard manual bypass for cut sheets
Media size Roll feed:
Width - 11 to 36 inches ( 279 to 914 mm)
Core diameter – 3 to 6.7 inches (76 to 170 mm)
Manual cut sheet feed:
Width - 11 to 36 inches (279 to 914 mm)
Minimum length – 8-1/2 inches (216 mm)
Print size Minimum:
Manual cut sheet feed (portrait) - 8-1/2 x 11 inches (216 x 279 mm)
Roll feed (landscape) – 11 x 8-1/2 inches (279 x 216 mm)
Maximum:
Manual cut sheet feed – 36 x 48 inches (914 x 1219 mm)
Roll feed - 36 inches x 80 feet (914 mm x 24 meters)
