Xerox Wide Format 6604 User Manual

Scanner Media Thickness
The Scanner Media Thickness setting adjusts the scanner controls to provide the best
image quality available for either thin or thick originals. The default is zero for normal
bond type.
NOTE
Skewed images can be incorrectly diagnosed as a need for Stitch Alignment
when a simple Scanner Media Thickness adjustment was needed instead.
1. Select Copy on the Services menu.
The Copy screen displays.
2. Select the Advanced Settings tab.
3. Select Scanner Media Thickness.
Prior to scanning the original, specify the thickness of it as listed below:
WeightNameTypeThicknessSetting
3 milNewsprintBondLight-1
18 lb. 3.5 mil.Translucent Bond-1
110 lb 7 milLight Card stockCard stock-1
4 milAccuImage Elite and MylarFilm-1
7-8 milLightPhoto Paper-1
20 lb. 4 milPremiumBondOrdinary0
20 lb. 4 milPerformance0
80 lb 9 milMedia Card stockCard stock0
90 g/m2Premium Tracing 90Vellum0
75 µmPremium Translucent 75 micronFilm0
80 lb 9 milPremiumPhoto Paper0
110 g/m2PresentationBondHeavy2
110 lb 11 milHeavy Card stockCard stock2
10 milHeavyPhoto Paper2
100 µmPremium Translucent 100 micronFilm2
112 g/m2Premium TracingVellum3
110 lb 13 milExtra Heavy Card stock/CoverCard stock3
* Tracing paper is displayed as [Vellum].
4. Adjust the setting as required.
5. Select Save when finished.
Xerox
®
Wide Format 6604/6605 Solution
™
2-22
User Guide
Printing and Copying Documents
