Xerox WorkCentre 3655 User Manual

Troubleshooting
Xerox
®
WorkCentre
®
3655/3655i Multifunction Printer 201
User Guide
Printer Fails to Power On
Probable Causes Solutions
One of the power switches is not turned on. Turn on both power switches. For details, see Turning the Printer On
and Off on page 37.
The power cord is not correctly plugged into
the outlet.
Turn off the printer power switch, and plug the power cord securely
into the outlet. For details, see Turning the Printer On and Off on
page 37.
Something is wrong with the outlet
connected to the printer.
• Plug another electrical appliance into the outlet and see if it
operates properly.
• Try a different outlet.
The printer is connected to an outlet with a
voltage or frequency that does not match the
printer specifications.
Use a power source with the specifications listed in the Electrical
Specifications on page 242.
CAUTION: Plug the three-wire cord with grounding prong directly into a grounded AC outlet.
Printer Resets or Turns Off Frequently
Probable Causes Solutions
The power cord is not plugged into the outlet
correctly.
Turn off the printer, confirm that the power cord is plugged in
correctly to the printer and the outlet, then turn on the printer.
A system error occurred. Turn off the printer, then turn it on again. Print the Error History
from the Information Pages of the Printer Setting Utility. If the error
persists, contact your Xerox representative.
The printer is connected to an uninterruptible
power supply.
Turn off the printer, then connect the power cord to a suitable
outlet.
The printer is connected to a power strip
shared with other high-power devices.
Plug the printer directly into the outlet or into a power strip that is
not shared with other high-power devices.
Document Prints From Wrong Tray
Probable Causes Solutions
Application and print driver have conflicting
tray selections.
1. Check the tray selected in the print driver.
2. Go to the page setup or printer settings of the application from
which you are printing.
3. Set the paper source to match the tray selected in the print
driver or set the paper source to Automatically Select.
Note: To have the print driver select the tray, set the tray used as
the paper source to Auto Selection Enabled.

Xerox WorkCentre 3655 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	9999 copies
Time to first copy (black, normal)	12 s
Input color depth	24 bit
Maximum scan area	216 x 356 mm
Image formats supported	JPG, TIF
Document formats supported	PDF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Digital sender	-
Maximum duty cycle	150000 pages per month
Page description languages	PCL 5c, PCL 6, PostScript 3
Wi-Fi	No
Security algorithms	FIPS 140-2, SNMP, SSL/TLS
Mobile printing technologies	Apple AirPrint, Xerox PrintBack
Supported network protocols (IPv6)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, PR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, NetWare: Bindery & NDS IPX/SPX, NDPS/NEPS, AppleTalk: EtherTalk, Microsoft Windows Networking over IP, Apple Bonjour IPv6, Secure FTP
Internal memory	2048 MB
Internal storage capacity	250 GB
Sound power level (standby)	31.9 dB
Sound pressure level (printing)	55.9 dB
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum input capacity	2350 sheets
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	60 sheets
Custom media width	139.7 - 216 mm
Custom media length	139.7 - 356 mm
Duplex media weight	60 - 125 g/m²
Paper tray media types	Bond paper, Card stock, Cut sheet, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 216 g/m²
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Blue, White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	82 W
Power consumption (average operating)	525 W
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	RoHS, ENERGY STAR
Certification	FCC, CE 2006/95/EC, 2004/108/EC & 1999/5/EC\\r UL 60950-1/CSA 60950-1-07, EAC, WEEE
Package depth	672 mm
Package width	653 mm
Package height	723 mm
Package weight	33000 g
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	541 mm
Width	560 mm
Height	577 mm
