ZC702 and ZVIK Getting Started Guide www.xilinx.com 31
UG926 (v3.0.1) February 12, 2013
Base TRD Hardware Setup Requirements
the display monitor should support 720p resolution: 1280 x 720p @ 60 Hz. If an HDMI
monitor is not available, a DVI monitor can be used, but an HDMI to DVI-D
cable/connector adapter is required (not included with the kit). The connector adapter
can be easily obtained at most electronic retailers or through a variety of online
sources.
Instructions for running the demonstration at 720p are provided in Running the Video
Demonstration for 720p Video Resolution, page 41.
Note:
The example mentioned in this package has been tested with a Dell model #P2412H
display monitor. However, the example should work well with any HDMI-compatible display
device.
• For the ZVIK, if running with an external video input source is desired, use the
FMC-IMAGEON HDMI input/output FMC module to connect an external video source.
An HDMI video source is required to provide the external video input. If an HDMI
source is not available, a DVI source can be used, but an HDMI to DVI-D
cable/connector adapter is required (not included with the kit). The connector adapter
can be easily obtained at most electronic retailers or through a variety of online
sources. The external video source must be 1080P 60 Hz and must not deliver content
with copy protection or Digital Rights Management (DRM) enabled. Many DVD and
media players output content with DRM enabled even if the content is not DRM
protected. A laptop or other source is recommended.
Note:
This TRD does not support input from the camera provided in the ZVIK. Check the ZVIK
product web page www.xilinx.com/ZVIK
for additional designs and resources.
Note: When connecting an external video source to the FMC card:
• Connect the source only after the bit file is programmed. Connecting the source only
after system boot-up is recommended.
• Ensure that the source resolution is set to the same resolution used by the demo (1080p
or 720p) as configured by the files on the SD card. See Running the Video
Demonstration for 720p Video Resolution, page 41 for more details.
• Ensure that the refresh rate for the source is set to 60 Hz.
