ZC702 and ZVIK Getting Started Guide www.xilinx.com 43
UG926 (v3.0.1) February 12, 2013
Chapter 4
Using the AMS101 Evaluation Card
Introduction
Each Xilinx Zynq-7000 AP SoC features two 1 MSPS, 12-bit, analog-to-digital converters
(ADCs) built into the device for everything from simple analog monitoring to more signal
processing-intensive tasks like linearization, calibration, over-sampling, and filtering. The
ZC702 evaluation kit includes the hardware and software to evaluate this ADC feature and to
determine its usefulness in the user’s end system.
For evaluation of Xilinx Agile Mixed Signal (AMS) capability, the following items in the kit are
needed:
• Access to the ZC702 XADC header
• AMS101 evaluation card (see Figure 4-1)
• Design and software files, which can be downloaded from the web
• Zynq-7000 AP SoC design programming files
• USB-UART drivers from Silicon Labs
•Blank
SD MMC card
