15
3
-1-5. Comm
unication port
RS
-
232
communication
DS2-
2□
P
□
-
AS/AS6, DS2-
20P4-BS/BS6
,
DS2-20
P7-BSW/BSW6,
DS2-21P5-AS
2,
DS2-
4□
P
□
-
AS/AS6
(5
-pin port)
Pin no.
Name
Explanation
1
TXD
RS232 send
2
RXD
RS232 receiv
e
3
GND
RS232 ground
RS
-
485
port
DS2-
2□
P
□
-
AS
/AS6, DS2-
4□
P
□
-
AS
/AS6
Pin no.
Name
CN1-
14
A
CN1-
15
B
(1)
Please use the ca
ble provide by XINJE Company.
(2)
For above
servo
drives,
RS232
(COM1)
and
RS485
(COM2)
cannot
be
used at
the
same time.
(3)
The
communication
paramete
rs
of
COM1
and
COM2
will
be
changed
at
the
same
time.
1
5
9
10
15
14
13
12
11
1
2
3
4
5
6
7
8
Comm
unication port(
RS232)
Can connect
PC and HMI
22
