Yamaha 01v 96 User Manual

1
2
3
4
5
6
7
8
9
10
11
12
10
ABCDEFGHIJKLMNOPQ
DCA CIRCUIT DIAGRAM (01V96)
DCA CIRCUIT DIAGRAM (01V96)
01V96
28CC1-8826685-1
1
REGULATOR +15V
µ
PC24A15HF
(
X3506A00
)
1
2
3
3: OUTPUT
2: GND
1: INPUT
NJM7915FA(XD854A00)
REGULATOR -15V
1
2
3
1: OUTPUT
2: INPUT
3: COMMON
NJM7905FA(XK309A00)
REGULATOR -5V
1
2
3
1: OUTPUT
2: INPUT
3: COMMON
REGULATOR +5V
µ
PC24A05HF
(
XM967A00
)
1
2
3
3: OUTPUT
2: COMMON
1: INPUT
to MAIN-CN005
to HA-CN551
to ADA-CN953
to Power Transformer
Components having special characteristics are marked and must be replaced with parts having
specifications equal to those originally installed.
TO SERVICE PERSONNEL
Critical Components Information
: Ceramic Capacitor
(セラミックコンデンサー)(
セ
)
: Mylar Capacitor
(マイラーコンデンサー)(
マ
)
: Metal Film Resistor
(金属被膜抵抗)(
F
)
: Metal Oxide Film Resistor
(酸化金属被膜抵抗)(
1P
)
SINGLE SHOT
REGULATOR +15V
REGULATOR -15V
REGULATOR -15V
REGULATOR +5V
REGULATOR -5V
