8-6
PORTABLE FUEL TANKS (TYPICAL)
FUEL PIPES (TYPICAL)
Ref. No. Part No.
Capacity
L (US gal)
Material Description
1
6YL-24201-05
12 (3.2) Plastic With fuel gauge
6YL-F4201-05
2
6YJ-24201-00 24 (6.3) Plastic
6YJ-24201-10 24 (6.3) Plastic With fuel gauge
6YJ-24201-40 24 (6.3) Plastic For JPN, With JCI label
6YJ-24201-50 24 (6.3) Plastic For CAN, With CSI label
6YJ-24201-80 24 (6.3) Plastic With tag and exclusive filler structure banning use of leaded fuel
3
6YK-24201-03
25 (6.6) Plastic With fuel gauge
6YK-F4201-02
6YK-24201-10 25 (6.6) Plastic With label and exclusive filler structure banning use of leaded fuel
6YK-24201-21 25 (6.6) Plastic For kerosene
Ref. No. Part No. Hose inside diameter Length (L) Remarks
1
6Y1-24306-55 6 mm 3 m (9.8 ft)
6Y2-24306-56 8 mm 3 m (9.8 ft)
2 6YK-24306-04 6 mm 3 m (9.8 ft) For kerosene models
123
mm (in.)mm (in.)mm (in.)
363 (14.3)
265 (10.4) 230 (9.1)
455 (17.9)
252 (9.9)314 (12.4)
536 (21.1)
233 (9.2)
362 (14.3)
(L)
(L)
12
To Next Page
