Components
20
EMU25802
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
EWM00020
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
licensing or approval authority regula-
tions.
1. Tachometer unit (Square type)*
2. Speedometer unit (Square type)*
3. Fuel management meter (Square type)*
1. Fuel joint
2. Fuel gauge
3. Fuel tank cap
4. Air vent screw
6C1-9-26-1E0.book 20 ページ ２０１０年２月１０日 水曜日 午後１時５３分
