Components
16
EMU25804
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
EWM00021
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
licensing or approval authority regula-
tions.
EMU25831
Fuel joint
This joint is used to connect the fuel line.
SET MODE
SET MODE
1
4
6
3
2
5
ZMU05429
1. Tachometer unit (Square type)*
2. Tachometer unit (Round type)*
3. Speedometer unit (Square type)*
4. Speed & fuel meter unit (Square type)*
5. Speed & fuel meter unit (Round type)*
6. Fuel management meter unit (Square type)*
1. Fuel joint
2. Fuel gauge
3. Fuel tank cap
4. Air vent screw
