Operation
64
EMU32852
Power trim and tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
ECM00261
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32914
Procedure for power trim and tilt models
1. Place the remote control lever / gear
shift lever in neutral.
2. Slightly tilt the outboard motor up to the
desired position using the power trim
and tilt switch. WARNING! Using the
power trim and tilt switch on the bot-
tom cowling while the boat is moving
or engine is on could increase the
risk of falling overboard and could
distract the operator, increasing the
risk of collision with another boat or
an obstacle.
[EWM01851]
3. To return the outboard motor to the nor-
6BG-9-78-1E0.book 64 ページ ２０１４年１１月２０日 木曜日 午後３時３分
