Operation
62
3. Slowly tilt the outboard motor down.
4. Place the tilt lock lever in the lock posi-
tion.
EMU44601
Procedure for tilting down (power
trim and tilt models)
1. Push the power trim and tilt switch “ ”
(up) until the outboard motor is support-
ed by the tilt rod and the tilt support knob
becomes free.
2. Pull out the tilt support knob.
3. Push the power trim and tilt switch “ ”
(down) to lower the outboard motor to
the desired position.
EMU28063
Shallow water
EMU28082
Hydro tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
DN
6BG-9-78-1E0.book 62 ページ ２０１４年１１月２０日 木曜日 午後３時３分
