Operation
60
2. Place the tilt lock lever in the release po-
sition.
3. Hold the rear of the top cowling with one
hand, tilt the engine up, and turn the tilt
support lever toward you or tilt support
knob into the clamp bracket, and then
place the tilt lock lever back into the lock
position to support the outboard motor.
NOTICE: Do not use the tilt support
lever or knob when trailering the
boat. The outboard motor could
shake loose from the tilt support and
fall. If the motor cannot be trailered in
the normal running position, use an
additional support device to secure it
in the tilt position. For more detailed
information, see page 66.
[ECM01642]
EMU44590
Procedure for tilting up (power trim
and tilt models)
1. Place the remote control lever / gear
shift lever in neutral.
2. Press the power trim and tilt switch “ ”
(up) until the outboard motor has tilted
up completely.
6BG-9-78-1E0.book 60 ページ ２０１４年１１月２０日 木曜日 午後３時３分
