Instruments and indicators
49
by connecting an optional sensor to the unit.
In addition, if optional sensors are connected
to the unit, water surface temperature dis-
play, depth display, and clock will also be
available. For the optional sensors, consult
your Yamaha dealer.
After the main switch is first turned to the
“ ” (on) position, all of the displays come on
as a test. After a few seconds, the unit will
change to normal operation.
For more information, see the operation
manual for the meters.
EMU41022
Command Link Multifunction
Fuel Management Meter
The fuel management meter has the func-
tions of fuel flow meter, total consumption
display, fuel economy display, and remaining
fuel display. The chosen display is selected
using the “ ” (set) and “ ” (mode) but-
tons as described in this section.
After the main switch is first turned to the
“ ” (on) position, all of the displays come on
as a test. After a few seconds, the unit will
change to normal operation.
For more information, see the operation
manual for the meters.
1. Set button
2. Mode button
1. Speedometer
2. Fuel meter
3. Multifunction display
1. Set button
2. Mode button
1. Fuel flow meter
2. Multifunction display
