4 - 60
ENG
STARTER CLUTCH
3. Install:
• starter wheel gear holder 1
• starter wheel gear holder bolt
NOTE:
Install the starter wheel gear holder in the
direction shown so that the section a of the
holder contacts the left crankcase.
4. Install:
• idle gear plate
• idle gear plate bolts
T
R
.
.
10 Nm (1.0 m · kg, 7.2 ft · lb)
T
R
.
.
10 Nm (1.0 m · kg, 7.2 ft · lb)

Yamaha Mio Specifications

General

Fuel System	Fuel Injection
Front Suspension	Telescopic Fork
Rear Suspension	Unit Swing
Overall Width	685 mm
Front Brake	Disc
Rear Brake	Drum
Fuel Tank Capacity	4.2 liters
Tire Size (Front)	70/90-14
Tire Size (Rear)	80/90-14
Starting System	Electric and kick starter
Wheelbase	1, 260 mm
Engine Type	Air-cooled, 4-stroke, SOHC
