2 - 22
SPEC
CABLE ROUTING
EAS00035
CABLE ROUTING
1
Front brake light switch lead
2
Right handlebar switch lead
3
Rear brake cable
4
Left handlebar switch lead
5
Rear brake light switch leads
6
Starter cable
7
Wire harness
8
Speedometer cable
9
Front brake hose
0
Throttle cable
È
Connect the meter assembly coupler on the left
side of the meter assembly.
É
Route the left handlebar switch lead behind the
handlebar, and then connect it on the left side of
the meter assembly.
Ê
To the headlight
1
2
3
4
6
7
8
9
0
6
3
8
7
9
0
A-A
È
É
Ê
Ë
Ì
Í
A
A
5
To Next Page
