MULTI MODE
35
Multi Play Mode
The Play mode (with the main Play display shown below) is the normal op-
erating mode of the MU80. To select the Play mode from any other mode,
press the PLAY button. (The Play mode is also automatically selected
when you turn on the MU80.)
NOTE
Applications that are capable of controlling 32 Parts (e.g., Performer) are set to a clock rate of
1 MHz.
Play Displays
The Play mode has three basic displays, that can be changed according to
your preference. Simply press the PLAY button repeatedly, and the display
alternates as shown below:
1)
Shows full “level meter” indication for the A1 and A2 A/D Parts and Parts
1 … 16. Currently selected parameter (here, Voice number and name) is
displayed at the right side.
Voice number and name for
currently selected Part.
MIDI port (A or B) and channel number for currently selected Part.
Current Part number.
Velocity “level meters” for each Part.
