REAR SHOCK ABSORBER ASSEMBLY
4-59
•
Connecting arm bolt (relay arm side)
•
Relay arm bolt (swingarm side)
•
Rear shock absorber assembly lower bolt
Connecting arm bolt (relay arm
side)
80 Nm (8.0 m·kgf, 58 ft·lbf)
Relay arm bolt (swingarm side)
70 Nm (7.0 m·kgf, 51 ft·lbf)
Rear shock absorber assembly
lower bolt
53 Nm (5.3 m·kgf, 38 ft·lbf)
T
R
.
.
T
R
.
.
T
R
.
.
182
184
