ENGINE REMOVAL
5-1
EAS1SM1195
This section is intended for those who have basic knowledge and skill concerning the servicing of
Yamaha motorcycles (e.g., Yamaha dealers, service engineers, etc.). Those who have little knowl-
edge and skill concerning servicing are requested not to undertake inspection, adjustment, disas-
sembly, or reassembly only by reference to this manual. It may lead to servicing trouble and
mechanical damage.
EAS1SM1196
ENGINE REMOVAL
Removing the exhaust pipe
Order Part name Q’ty Remarks
Side cover (right) Refer to “GENERAL CHASSIS” on page 4-1.
Rear shock absorber assembly lower bolt
Refer to “REAR SHOCK ABSORBER AS-
SEMBLY” on page 4-53.
Connecting arm bolt (frame side)
Refer to “REAR SHOCK ABSORBER AS-
SEMBLY” on page 4-53.
1 Silencer clamp 1 Loosen.
2 Silencer 1
3 Exhaust pipe 2 clamp 1 Loosen.
4 Exhaust pipe 2 1
5 Exhaust pipe 1 1
6 Gaskets 3
10
5
9
2
6
1
6
6
3
8
4
7
(8)
(6)
30 Nm (3.0 m
•
kgf, 22 ft
•
Ibf)
T
.R
.
30 Nm (3.0 m
•
kgf, 22 ft
•
Ibf)
T
.R
.
8 Nm (0.8 m
•
kgf, 5.8 ft
•
Ibf)
T
.R
.
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
New
New
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R.
20 Nm (2.0 m
•
kgf, 14 ft
•
Ibf)
T
.R
.
New
1st
2nd 20 Nm (2.0 m
•
kgf, 14 ft
•
lbf)
13 Nm (1.3 m
•
kg , 9.4 ft
•
lbf)
T
.R
.
LT
LT
LT
To Next Page
