CRANKCASE
5-62
8 Left crankcase 1
9 Dowel pin 2
10 Crankshaft 1
11 Oil passage squeeze nozzle 1
For assembly, reverse the disassemble pro-
cedure.
Separating the crankcase
Order Part name Q’ty Remarks
10 Nm (1.0 m
•
kgf, 7.2 ft
•
Ibf)
T
.R
.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R
.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R
.
12 Nm (1.2 m
•
kgf, 8.7 ft
•
Ibf)
T
.R.
3
1
5
2
6
4
10
5
6
4
4
4
4
6
911
7
8
9
LT
