Yealink SIP-T46S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 18 OF 150
3 BroadWorks Configuration
This section identifies the required BroadWorks device profile type for the Yealink T4x IP
Phone as well as any other unique BroadWorks configuration required for interoperability
with the T4x IP Phone.
3.1 BroadWorks Device Profile Type Configuration
This section identifies the device profile type to use when deploying the Yealink T4x IP
Phone with BroadWorks.
Create a device profile type for the Yealink T48G IP Phone as shown in the following
example. A separate device profile type should be created for each Yealink T4x IP Phone
model. The settings shown are recommended for use when deploying the Yealink T4x IP
Phone with BroadWorks. For an explanation of the profile parameters, see the
BroadWorks Device Management Configuration Guide [2].
The following device profile type shown provides the Number of Ports (number of SIP
lines) setting for Yealink T4x IP Phone. For other Yealink T4x IP Phone models, create a
new device profile type and set the Number of Ports to match the available number of SIP
lines per model according to the following table.
Model Number of Lines
T40P 3 SIP accounts, 3 line keys
T40G 3 SIP accounts, 3 line keys
T41P 6 SIP accounts, 15 line keys
T41S 6 SIP accounts, 15 line keys
T42G 12 SIP accounts, 15 line keys
T42S 12 SIP accounts, 15 line keys
T46G 16 SIP accounts, 27 line keys
T46S 16 SIP accounts, 27 line keys
T48G 16 SIP accounts, 29 line keys
T48S 16 SIP accounts, 29 line keys
T49G 16 SIP accounts, 29 line keys

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
