Yealink SIP-T46S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 27 OF 150
Figure 5 Account Register Page
Third, all of the advanced setting of the host and the other appearance line must enable
the BroadSoft SCA feature. Browse to Account →Advanced →Shared Line.
Figure 6 Shared Line Field
The following steps are used to assign multiple line keys to Line for Bob’s phone.
Step Command Purpose
Step 1 Set DSS Key.
Example:
linekey.1.type =15
linekey.1.line = 1
Set memory key to line and
apply this key type (line) to
the shared line.
key type: 15-line
line ID:
0:line1
1:line1
2:line2
3:line3
4:line4
5:line5
6:line6
T40P have 3 line keys
T41P/T41S/T42G/T42S have
15 line keys
T46G/T46S have 27 line keys
T48G/T48S/T49G have 29
line keys

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
