Yealink SIP-T46S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 29 OF 150
Step Command Purpose
Step 1 features.auto_linekeys.enable =
Example:
features.auto_linekeys.enable = 1
Enable setting line keys to
shared lines auto
0 = disable
1 = enable
Step 2 account.x.number_of_linekey =
Example:
account.1.number_of_linekey = 5
Set the number of line keys
which you want to auto
configure to shared line keys.
Value range: 1 to 99999
4.3.2 Busy Lamp Field Configuration
The Busy Lamp Field (BLF) implementation provides an attendant console function.
Configuration of the phone to enable Busy Lamp Field is described as follows.
Step Command Purpose
Step 1 Set the BLF List URI for the line.
Example:
account.1.blf.blf_list_uri =
u1062_blflist@as.iop1.broadworks.net
The BLF List URI must be
configured to match the
BroadWorks settings.
Browse to Account → Advanced → BLF List URI/BLF List Code/BLF List Barge In Code
to configure the BLF settings.
Figure 10 BLF Settings
On the BroadWorks server, browse to Client Applications → Busy Lamp Field and
configure the settings as shown in the following figure.
Figure 11 Busy Lamp Field Configuration Page

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
