Yealink SIP-T46S Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 40 OF 150
Figure 23 Xtended Services Platform Configuration
4.4.1 BroadWorks User Service Configuration
Integration with the BroadWorks Xtended Services Interface for User Service
Configuration enables the phone to display and configure BroadWorks user services, such
as Remote Office, BroadWorks Anywhere, Call Forwarding, and Simultaneous Ring. To
enable User Service Configuration, perform the following steps.
Step Command Purpose
Step 1 bw.xsi.enable =
Example:
bw.xsi.enable = 1
Enable XSI feature.
 0 for Disabled
 1 for Enable
Step 2 sip.authentication_for_xsi =
Example:
sip.authentication_for_xsi = 1
Enable the Xsp authentication
mode.
 0= BroadWorks User Login
credentials
 1= SIP Authentication
credentials
Step 3 account.1.xsi.user=
account.1.xsi.password =
Example:
account.1.xsi.user= 2405551111
account.1.xsi.password = 123456
Set the Xsi login user name
and password for line 1.
Step 4 account.1.xsi.host =
Example:
account.1.xsi.host =xsp1.iop1.broadworks.net
Set the IP address or domain
name of the Xsp server.

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
